MiBoxer HW5 5 In 1 WiFi Smart Strip LED Strip Dimmers Controller 12V-48V

Tool-free instant wiring
• Support “Tuya Smart” app control, Support music rhythm
• Support third party voice control (Alexa, Google Assistant)
• 2.4G RF Remote controllable
• 16 Millions of colors to choose, color temperature adjustable, brightness and saturation controllable
•
Switching 5 output mode via one summary (Single color / Dual white / RGB / RGBW / RGB+CCT)

This product uses WiFi + Bluetooth + 2.4G wireless transmission technology, low power consumption, strong anti-interference ability. WiFi + Bluetooth connect network can greatly enhance the connect network experience. When the router is disconnected, Bluetooth can also directly connect and control equipment at close range. After successful network configuration using [Tuya Smart] app to achieve wireless dimming, remote control, group control, scene control, timing control, music movement, biorhythm, sleep plan, wake plan, one key execution, automation, etc. functions. And it supports 2.4G remote control.

One lighting fixtures can transmit the signals from the remote control to another lighting fixtures within 30m, as long as there is a lighting fixtures within 30m, the remote control distance can be limitless.

Experience seamless wireless control with an unobstructed range of up to 30 meters. Utilize wireless control via handset or wallplate, for effortless operation, achieve precise brightness adjustments with the push dimming feature and synchronize lighting across multiple receivers.

Specification:
Product – 5 in 1 LED Strip Controller (WiFi+2.4G)
Model – HW5
Input Voltage – DC 12V – 48V
Output – 15A/Channel
Total Output – Max 30A
Communication Protocol – WIFI + 2.4GHz
2.4 RF Control Distance – 30 Metre
IP Rating – IP20
Working Temperature – -10~40°C
WiFi Standard – IEEE 802.11b/g/n 2.4GHz
Bluetooth Protocol –
Bluetooth 4.2 (low power consumption)
Size – 134mm x 81mm x 24mm

User Manual:
